LiYCY Control Cable/ Data Cable

  • LiYCY

  • 100m,250m, 305m,500m,1000m,500ft,1000ft

  • roll, plastic reel ,carton reel ,wooden spool, carton, pallet

  • 10KM

  • NINGBO, SHANGHAI

  • T/T, L/C, D/P at sight

  • CPR, CE, RoHS,ISO9001,REACH

  • Normally 20 working days

  • Bare Copper

  • PVC

Availability:

LiYCY Control Cable/ Data Cable

Application:

LiYCY cable can be used for signal transmission between electronic devices, in computer systems or process control units with increased electromagnetic compatibility requirements.

Product Description

Conductor

Bare copper strands with reference to VDE 0812

Insulation

PVC, TI2 acc. to EN 50363-3, VDE 0207-363-3

Colour code

With reference to DIN 47100

Stranding

In layers

Wrapping

PETP foil

Screen

Tinned copper braiding

Sheath material

PVC, TM2 acc. to EN 50363-4-1, VDE 0207-363-4-1

Sheath colour

Grey (RAL 7032)

Characteristics

Peak operating voltage

< 0.25 mm&sup2; = max. 350 V
≥ 0.25 mm&sup2; = max. 500 V

Testing voltage

core/core 1500 V
core/screen 1200 V

Min. bending radius


fixed laying:

 5 x d

flexible application:

10 x d

Temperature range


fixed laying:

-30/+70 &deg;C

flexible application:

-5/+70 &deg;C

Fire performance

flame retardant and self-extinguishing acc. to IEC 60332-1-2 , VDE 0482-332-1-2
