LiYY Control Cable/ Data Cable

  • LiYY

  • 100m,250m, 305m,500m,1000m,500ft,1000ft

  • roll, plastic reel ,carton reel ,wooden spool, carton, pallet

  • 10KM


  • T/T, L/C, D/P at sight


  • Normally 20 working days

  • Bare Copper

  • PVC


LiYY Control Cable/ Data Cable


This cable can be used for signal transmission between electronic devices, in computer systems or process control units.

Product Description


Bare copper strands with reference to VDE 0812


PVC, TI2 acc. to EN 50363-3, VDE 0207-363-3

Colour code

With reference to DIN 47100

Sheath material

PVC, TM2 acc. to EN 50363-4-1, VDE 0207-363-4-1

Sheath colour

Grey (RAL 7032)


Peak operating voltage

< 0.25 mm&sup2; = max. 350 V
≥ 0.25 mm&sup2; = max. 500 V

Testing voltage

core/core 1500 V

Min. bending radius

fixed laying:

 5 x d

flexible application:

10 x d

Temperature range

fixed laying:

-30/+70 &deg;C

flexible application:

-5/+70 &deg;C

Fire performance

flame retardant and self-extinguishing acc. to IEC 60332-1-2 , VDE 0482-332-1-2

The Factory

Hangzhou Aite Cable Co., LTD. is one of the leading manufacturers of coaxial cables,lan cables, security cables, alarm cables, and CCTV cables for camera etc,. With certification of CE, ROHS Compliant, and ISO 9001. Our factory is located in Lin'an, Hangzhou, China, which is only 200kms away from Shanghai, and 40kms away from Hangzhou.

Founded in 2012, our company has blossomed into one of the largest independent manufacturer and exporter in China. We have a study and design team, a professional team of engineers and skilled workers, and also advanced lines and machines which can provide our customers with outstanding quality, service, and price.


Why choose us

Good Price

We provide good factory price to to ensure your profit.

Quality Control

We perform strict inspections on raw materials and production processes. There are four QC steps before cables leave factory. 1. Raw materials incoming test 2. Semi-finished product test for each production line . 3. Finished product test(Construction & Electrical Characteristics) 4. Cable power test and package inspection.

On-time Delivery

Our monthly output is 6000KM. Sample available in 7 days, and normal order delivery time is only 15-25 days.


Our technical team has rich experience in developing various specifications of cables for customized orders. According to the customized requirements, our team are capable to provide suggestions and designs.

Reliable Service

For before-order stage, our professional sales team are ready to reply your inquiry at first time during working hours and within 12 hours at close time to help you win your client with perfect option at high efficiency.

For order-running stage, our professional service team will update the production and provide documents for shipment in time .

For after-sale stage, our service team always keep close contact with you and always stand by at your service. We’re responsible for all the products during its normal lifetime.
