P3 412
Construction
Material | Diameter(mm) | |
Inner Conductor | CCA | 2.26 |
Dielectric | Foam PE | 4.80 |
First Shield | Solid AL tube | |
Jacket | PE | 12.07 |
Electrical Characteristics
Impedance (Ω) | 75±3 |
Capacitance (pF/m) | 52±2 |
Velocity of Propagation(﹪) | 87.0 |
Return Loss | |
5-1000MHz(dB) | ≥22 |
Attenuation(@20℃)
| Frequency (MHZ) | Max Attenuation (dB/100m) |
| 5 | 0.66 |
55 | 2.26 |
83 | 2.82 |
211 | 4.63 |
250 | 5.05 |
| 300 | 5.58 |
| 350 | 6.14 |
| 400 | 6.46 |
| 500 | 7.35 |
| 750 | 9.12 |
| 865 | 9.84 |
| 1000 | 10.73 |
