Type B
100m,250m, 305m,500m,1000m,500ft,1000ft
roll, plastic reel ,carton reel ,wooden spool, carton, pallet
10KM
NINGBO, SHANGHAI
T/T, L/C, D/P at sight
CPR, CE, RoHS,ISO9001,REACH
Normally 20 working days
Solid Copper
PVC/LSZH
harsh environment, outdoors, data transmission applications, Instrumentation and computer cable, etc. exposure to temperature extremes, humidity/moisture, dust, and oil.
Construction |
Material | Diameter(mm) | |
Conductor | Solid Copper(Class1) | 22AWG/7*30AWG |
Insulation | PE | 1.5mm |
Insulation color | White,Yellow,Blue,Orange | / |
Inner jacket | PVC or LSZH | 3.9mm |
First Shield | AL/Mylar screen | 100% |
Second shield | TC braid | 65% |
Out jacket | PVC/LSZH | 6.5mm |
Color | Green RAL 6018 | / |
Technical parameters |
Temperature range | -40℃ to 80℃ |
Characteristic impedance | 100±15Ohm |
Min bending radius | Fixed installation |
Loop conductor DC resistance at 20℃ | ≦60Ohm/km |
Test voltage | 2000V/min(AC) |
Operating voltage | 80V |
The Factory |
Hangzhou Aite Cable Co., LTD. is one of the leading manufacturers of coaxial cables，lan cables, security cables, alarm cables, and CCTV cables for camera etc,. With certification of CE, ROHS Compliant, and ISO 9001. Our factory is located in Lin'an, Hangzhou, China, which is only 200kms away from Shanghai, and 40kms away from Hangzhou.
Founded in 2012, our company has blossomed into one of the largest independent manufacturer and exporter in China. We have a study and design team, a professional team of engineers and skilled workers, and also advanced lines and machines which can provide our customers with outstanding quality, service, and price.
Packing |
Why choose us |
Good Price
We provide good factory price to to ensure your profit.
Quality Control
We perform strict inspections on raw materials and production processes. There are four QC steps before cables leave factory. 1. Raw materials incoming test 2. Semi-finished product test for each production line . 3. Finished product test(Construction & Electrical Characteristics) 4. Cable power test and package inspection.
On-time Delivery
Our monthly output is 6000KM. Sample available in 7 days, and normal order delivery time is only 15-25 days.
R&D
Our technical team has rich experience in developing various specifications of cables for customized orders. According to the customized requirements, our team are capable to provide suggestions and designs.
Reliable Service
For before-order stage, our professional sales team are ready to reply your inquiry at first time during working hours and within 12 hours at close time to help you win your client with perfect option at high efficiency.
For order-running stage, our professional service team will update the production and provide documents for shipment in time .
For after-sale stage, our service team always keep close contact with you and always stand by at your service. We’re responsible for all the products during its normal lifetime.
