RG11 Standard Coaxial Cable

Length:100m,250m, 305m,500m,1000m,500ft,1000ft Packing:roll, plastic reel ,carton reel ,wooden spool, carton, pallet MOQ:10KM Delivery time:Normally 20 working days Port of Loading:NINGBO, SHANGHAI Term of payment:T/T, L/C, D/P at sight Certificates:CPR, CE, RoHS,ISO9001,REACH
  • RG11 Standard
  • CCS/BC
  • PVC
Availability:

RG11 Standard

Construction


Material

Diameter(mm)

Inner Conductor

CCS/BC

1.63

Dielectric

Foam PE

7.11

First Shield

AL Foil


Second Shield

AL/BC Braid

60%-90%

Jacket

PVC

10.16


Electrical Characteristics

Impedance (Ω)

 75±3

Capacitance (pF/m)

 52±2

Velocity of Propagation(﹪)

 85.0

Return Loss


5-1000MHz(dB)

≥22

1000-3000MHz(dB)

≥20


Attenuation(@20℃)

Frequency (MHZ)

Max Attenuation (dB/100ft)

Max Attenuation (dB/100m)

5

0.4

 1.3

55

1.0

 3.2

187

1.7

 5.7

  211

1.9

6.2

 400

 2.6

 8.5

 500

   2.9

 9.5

 750

3.6

 11.9

 860

    4.0

 13.1

  1000

    4.3

 14.3

 1500

     5.1

 16.8

 1800

 5.7

 18.6

2200

 6.3

 20.7

 3000

  7.6

 24.9
