RGB 5 Core Combo Cable

Length:100m,250m, 305m,500m,1000m,500ft,1000ft
Packing:roll, plastic reel ,carton reel ,wooden spool, carton, pallet
MOQ:10KM
Delivery time:Normally 20 working days
Port of Loading:NINGBO, SHANGHAI
Term of payment:T/T, L/C, D/P at sight
Certificates:CPR, CE, RoHS,ISO9001,REACH
  • RGB 5 Core
Availability:

RGB 5 Core

图纸

RGB 5 cores  Construction


Material

Diameter(mm)

Inner Conductor

BC

0.57

Dielectric

Foam PE

2.54

Out Conductor

AL Foil+ TC Braiding

95%

One core Jacket

PVC

4.00

Binder

 paper wrap

11.00

Out jacket

PVC 13.70


Electrical Characteristics

Impedance (Ω)

 75

 Nominal Capacitance (pF/m)

 59

Velocity of Propagation(﹪)

78

Sparker Test

4000

SRL(dB)

20


Attenuation(@20℃)

Frequency (MHZ)

Max Attenuation (dB/100ft)

Max Attenuation (dB/100m)

10

  1.29

 4.23

270

  5.92

 19.42

360

 6.70

 21.98

  720

 9.47

 31.06

 1000

 11.16

 36.60

 1500

    13.67

 44.84

 2000

 15.78

  51.76

  2500

    16.74

  54.91

  3000

   19.33

  63.40
