SAT602
100m,250m, 305m,500m,1000m,500ft,1000ft
roll, plastic reel ,carton reel ,wooden spool, carton, pallet
10KM
NINGBO, SHANGHAI
T/T, L/C, D/P at sight
CPR, CE, RoHS,ISO9001,REACH
Normally 20 working days
CCS/BC
PVC
SAT602
Construction
Material | Diameter(mm) | |
Inner Conductor | CCS/BC/ | 1.02 |
Dielectric | Foam PE | 4.60 |
First Shield | AL Foil | |
Second Shield | AL/BC/ Braid | 35% |
| Jacket | PVC | 6.80 |
Electrical Characteristics
Impedance (Ω) | 75±3 |
Capacitance (pF/m) | 52±2 |
Velocity of Propagation(﹪) | 85.0 |
Return Loss | |
5-1000MHz(dB) | ≥22 |
| 1000-3000MHz(dB) | ≥20 |
Screening Effectiveness | |
5-1000MHz(dB) | ≥70 |
Attenuation(@20℃)
| Frequency (MHZ) | Max Attenuation (dB/100m) |
5 | 1.9 |
| 50 | 4.9 |
| 100 | 7.1 |
200 | 9.0 |
400 | 13.0 |
800 | 18.7 |
1000 | 21.0 |
1350 | 25.5 |
| 1750 | 28.5 |
| 2150 | 32.2 |
| 2400 | 35.0 |
| 3000 | 40.6 |
SAT602
Construction
Material | Diameter(mm) | |
Inner Conductor | CCS/BC/ | 1.02 |
Dielectric | Foam PE | 4.60 |
First Shield | AL Foil | |
Second Shield | AL/BC/ Braid | 35% |
| Jacket | PVC | 6.80 |
Electrical Characteristics
Impedance (Ω) | 75±3 |
Capacitance (pF/m) | 52±2 |
Velocity of Propagation(﹪) | 85.0 |
Return Loss | |
5-1000MHz(dB) | ≥22 |
| 1000-3000MHz(dB) | ≥20 |
Screening Effectiveness | |
5-1000MHz(dB) | ≥70 |
Attenuation(@20℃)
| Frequency (MHZ) | Max Attenuation (dB/100m) |
5 | 1.9 |
| 50 | 4.9 |
| 100 | 7.1 |
200 | 9.0 |
400 | 13.0 |
800 | 18.7 |
1000 | 21.0 |
1350 | 25.5 |
| 1750 | 28.5 |
| 2150 | 32.2 |
| 2400 | 35.0 |
| 3000 | 40.6 |
